AAT3526ICX-2.63-200-T1

MicroPower Supervisory Circuit with Manual Reset, 1.2V to 5.5V, 2μA, SOT143

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.05~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.05~1.00

PartNumber:: AAT3526ICX-2.63-200-T1

Brand:: Advanced Analog Technology, Inc. - AAT | Pack: SOT | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Jolin's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-10-26

From Other Seller

Part Number:AAT3526ICX-2.63-200-T1
US $0.05 - 1.00
IRF3205

US $0.80 - 2.50 / Piece
(0) Remove
STK795-810

US $12.00 - 16.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AAT3526ICX-2.63-200-T1 is a MicroPower Supervisory Circuit with Manual Reset. It is ideal for monitoring voltage supplies in portable systems, where extended battery life is critical. The applications of the AAT3526ICX-2.63-200-T1 include cell phones, embedded systems, intelligent instruments, notebook computers, portable electronics.

Parametrics

AAT3526ICX-2.63-200-T1 absolute maximum ratings:(1)VCC, VCC to GND: -0.3 to 5.5V; (2)VMR, MR to GND: -0.3 to VCC+0.3V; (3)VRESET, RESET to GND: -0.3 TO 5.5V; (4)IVCC,IMR, maximum continuous input current:20mA; (5)IRESET, RESET/RESET current: 20mA; (6)dVCC/dt, rate of rise fo V: 100V/μs; (7)TJ, Operating junction temperature range: -40 to 150℃; (8)TLEAD, maximum soldering temperature for 10s: 300℃.

Features

AAT3526ICX-2.63-200-T1 features: (1)Input voltage range: 1.2V to 5.5V; (2)Operation down to 1.2V; (3)Extremely low quiescent current less than 2μA; (4)High accuracy detection threshold: ±1.5%; (5)Monitor power supply voltages; (6)Fixed thresholds from 2.2V to 4.6V; (7)Minimum 150ms Reset pulse width with fast delay time＜20μs; (8)Debounced manual reset input; (9)Available output configurations; (10)Temperature range: -40 to +85℃; (11)4-pin SOT143 package; (12)4kV ESD ratings.
