AT24C128

2-wire Serial EEPROM, 128KBIT, 1MHZ, 8DIP, AT24C128

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~100.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~100.00

PartNumber:: AT24C128

Brand:: ATMEL Corporation - ATMEL | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Jolin's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-02

From Other Seller

Part Number:AT24C128
US $1.00 - 100.00
LM285M-2.5

US $0.16 - 0.25 / Piece
(0) Remove
HM62256BLFP-10T

US $0.65 - 0.80 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT24C128 EEPROM provides 131,072/262,144 bits of serial electrically erasable and programmable read only memory (EEPROM) organized as 16,384/32,768 words of 8 bits each. The AT24C128 is optimized for use in many industrial and commercial applications where low power and low voltage operation are essential. The AT24C128 is available in space-saving 8-pin JEDEC PDIP, 8-pin JEDEC SOIC, 8-pin EIAJ SOIC, 8-pin TSSOP, 14-pin TSSOP and 8-ball dBGA packages.

Parametrics

AT24C128 absolute maximum ratings: (1)Operating Temperature: -55 to +125℃; (2)Storage Temperature:-65 to +150℃; (3)Voltage on Any Pin with Respect to Ground:-1.0V to +7.0V; (4)Maximum Operating Voltage:6.25V; (5)DC Output Current:5.0 mA.

Features

AT24C128 features: (1)Internally Organized 16,384 x 8 and 32,768 x 8; (2)2-wire Serial Interface; (3)Schmitt Trigger, Filtered Inputs for Noise Suppression; (4)Bidirectional Data Transfer Protocol; (5)1 MHz (5V), 400 kHz (2.7V, 2.5V) and 100 kHz (1.8V) Compatibility; (6)Write Protect Pin for Hardware and Software Data Protection; (7)64-byte Page Write Mode (Partial Page Writes Allowed); (8)Self-timed Write Cycle (5 ms Typical); (9)High Reliability: Endurance: 100,000 Write Cycles.
