MAX2632EUK+T

MAX2632EUK+T, SOT, General-Purpose Amplifier, 100uA, +2.7V to +5.5V, 13.4dB

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.01~0.05 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
100 ~ 10000 :	0.05 / Piece
10000 ~ 50000 :	0.01 / Piece

PartNumber:: MAX2632EUK+T

Brand:: Maxim Integrated Products - Maxim | Pack: SOT | D/C: 10+

Availability:: Supply Ability: 50000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Jolin's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-18

From Other Seller

Part Number:MAX2632EUK+T
US $0.01 - 0.05
Quantity:

piece

Product Summary

The MAX2632EUK+T is a lowvoltage, low-noise amplifier for use from VHF to microwave frequency. Operating from a single +2.7V to +5.5V supply, the MAX2632EUK+T has a flat gain response to 900MHz. The low noise figure and low supply current of the MAX2632EUK+T makes its ideal for receive, buffer, and transmit IF applications. The MAX2632EUK+T is biased internally, eliminating the need for external bias resistors or inductors. The MAX2632EUK+T has a user-selectable supply current, which can be adjusted by adding a single external resistor. This allows customized output power and gain according to specific applications requirements. The MAX2632EUK+T features a shutdown pin that allows them to be powered down to less than 1μA supply current. Aside from a single bias resistor required for the MAX2632EUK+T, the only external components needed for this family of amplifiers are input and output blocking capacitors and a VCC bypass capacitor.

Parametrics

MAX2632EUK+T absolute maximum ratings: (1)VCC to GND -0.3V to 6V; (2)Input Power 5dBm; (3)OUT Current ±12mA; (4)IN to GND Voltage -1.2V to 1.2V; (5)Bias to GND Voltage 0.0V to 3V; (6)Voltage at SHDN Input -0.3V to (VCC + 0.3V); (7)Current into SHDN Input 100μA; (8)Operating Temperature Range -40℃ to +85℃; (9)Junction Temperature +150℃; (10)Storage Temperature Range -65℃ to +150℃; (11)Lead Temperature (soldering, 10s) +300℃.

Features

MAX2632EUK+T features: (1)Single +2.7V to +5.5V Operation; (2)Internally Biased (MAX2630/MAX2631); (3)Adjustable Bias (MAX2632/MAX2633); (4)6.6mA Supply Current (insensitive to supply; (5)voltage); (6)1μA Shutdown Current (MAX2631/MAX2633); (7)3.7dB Noise Figure; (8)13.4dB Gain; (9)Ultra-Small SOT Packages.
