Product Summary
The MAX8519EEE+T is an ultra-low-noise, lowdropout (LDO) linear regulator. It is designed to deliver up to 120mA continuous output current from a tiny 5-pin SC70 plastic package. These regulators achieve a low 120mV dropout for 120mA load current. The MAX8519EEE+T uses an advanced architecture to achieve ultra-low output voltage noise of 11μVRMS and PSRR of 54dB at 100kHz. The applications of the MAX8519EEE+T include Cellular and Cordless Phones, PDA and Palmtop Computers, Base Stations, Bluetooth Portable Radios and Accessories, Wireless LANs, Digital Cameras, Personal Stereos, Portable and Battery-Powered Equipment.
Parametrics
MAX8519EEE+T absolute maximum ratings: (1)IN to GND: -0.3V to +7V; (2)Output Short-Circuit Duration: Infinite; (3)OUT, SHDN to GND: -0.3V to (IN + 0.3V); (4)FB, BP, N.C. to GND: -0.3V to (OUT + 0.3V); (5)Continuous Power Dissipation (TA = +70℃) 5-Pin SC70 (derate 3.1mW/℃ above +70℃): 0.247W; (6)θJA (5-Pin SC70): 324℃/W; (7)Operating Temperature Range: -40℃ to +85℃; (8)Junction Temperature: +150℃; (9)Storage Temperature Range: -65℃ to +150℃; (10)Lead Temperature (soldering, 10s): +300℃.
Features
MAX8519EEE+T features: (1)Space-Saving 5-Pin SC70 Package; (2)11μVRMS Output Noise at 100Hz to 100kHz; (3)Bandwidth (MAX8510); (4)78dB PSRR at 1kHz (MAX8510); (5)120mV Dropout at 120mA Load; (6)Stable with 1μF Ceramic Capacitor for Any Load; (7)Guaranteed 120mA Output; (8)Only Need Input and Output Capacitors (MAX8511); (9)Output Voltages: 1.5V, 1.8V, 2.5V, 2.6V, 2.7V, 2.8V, 2.85V, 3V, 3.3V, 4.5V (MAX8510/MAX8511) and Adjustable (MAX8512); (10)Low 40μA Ground Current; (11)Excellent Load/Line Transient; (12)Overcurrent and Thermal Protection.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
MAX8519EEE+T |
Maxim Integrated Products |
Low Dropout (LDO) Regulators LDO |
Data Sheet |
|
|
|||||||||||||
