OP07

OP07CP, Ultralow Offset Voltage Operational Amplifier, DIP, 600kHz, 1.8nA, 60μV

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~50.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~50.00

PartNumber:: OP07

Brand:: Texas Instruments - TI | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Jolin's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-06-05

From Other Seller

Part Number:OP07
US $1.00 - 50.00
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The OP07 is an Ultralow Offset Voltage Operational Amplifier. It has very low input offset voltage (75 μV maximum for OP07E) that is obtained by trimming at the wafer stage. The low offset voltage generally eliminates any need for external nulling. The OP07 also features low input bias current (±4 nA for the OP07E) and high open-loop gain (200 V/mV for the OP07E). The low offset and high open-loop gain make the OP07CP particularly useful for high gain instrumentation applications. The applications of the OP07 include Wireless base station control circuits, Optical network control circuits, Instrumentation, Sensors and controls.

Parametrics

OP07 absolute maximum ratings: (1)Supply Voltage (VS): ±22 V; (2)Input Voltage: ±22 V; (3)Differential Input Voltage: ±30 V; (4)Output Short-Circuit Duration Indefinite Storage Temperature Range: S and P Packages: -65℃ to +125℃; (5)Operating Temperature Range: -40℃ to +85℃; (6)Junction Temperature: 150℃; (7)Lead Temperature, Soldering (60 sec): 300℃.

Features

OP07 features: (1)Low VOS: 75 μV maximum; (2)Low VOS drift: 1.3 μV/℃ maximum; (3)Ultrastable vs. time: 1.5 μV per month maximum; (4)Low noise: 0.6 μV p-p maximum; (5)Wide input voltage range: ±14 V typical; (6)Wide supply voltage range: 3 V to 18 V; (7)125℃ temperature-tested dice.
