CD4081

CMOS AND gate, 14-Pin CDIP, 0.3V, 60 ns, 1 μA, 500 mW, CD4081

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~50.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~50.00

PartNumber:: CD4081

Brand:: Texas Instruments - TI | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Jolin's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-06-06

From Other Seller

Part Number:CD4081
US $1.00 - 50.00
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
YL-G709

US $65.00 - 68.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The CD4081 is a CMOS AND gate which provides the system designer with direct implementation of the AND function and supplement the existing family of CMOS gates. The CD4081 is supplied in 14-lead hermetic dual-in-line ceramic packages.

Parametrics

CD4081 absolute maximum ratings: (1)DC supply-voltage range, VDD: -0.5 to +20 V; (2)input voltage range, all inputs: -0.5 V to VDD+0.5 V; (3)DC input current, any one input: ± 10 mA; (4)power dissipation per package: 500 mW; (5)device dissipation per output transistor for TA=fullpackage-temperature range: 100 mW; (6)operating temperature range: -55 to +125℃; (7)storage temperature range: -65 to +150℃; (8)lead temperature: +265℃.

Features

CD4081 features: (1)medium speed operation: tpHL, tpHL=60 ns at VDD=10 V; (2)100% tested for quiescent current at 20 V; (3)maximum input current of 1 μA at 18 V over full package-temperature range: 100nA at 18V and 25 ℃; (4)standardized symmetrical output characteristics; (5)5-V, 10-V and 15-V parametric ratings.
