Product Summary

The ESDALC6V1W5 is a 4-bit wide monolithic suppressor which is designed to protect component connected to data and transmission lines against ESD. It clamps the voltage just above the logic level supply for positive transients, and to a diode drop below ground for negative transients. The ESDALC6V1W5 is suitable for where transient overvoltage protection in ESD sensitive equipment is required, such as: (1)Computers; (2)Printers; (3)Communication systems and cellular phones; (4)Video equipment; (5)Set top boxes.

Parametrics

ESDALC6V1W5 absolute maximum ratings: (1)PPP Peak pulse power: 25 W; (2)Tj Junction temperature: 150℃; (3)Tstg Storage temperature range: -55 to +150℃; (4)Top Operating temperature range: -40 to 150℃.

Features

ESDALC6V1W5 features: (1)4 unidirectional TRANSIL? functions.; (2)ESD Protection: IEC61000-4-2 level 4; (3)Breakdown voltage VBR = 6.1V min; (4)Low leakage current < 1μA@3 Volts; (5)Low capacitance device.

Diagrams

ESDALC6V1W5 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
ESDALC6V1W5
ESDALC6V1W5
STMicroelectronics
TVS Diode Arrays 25W 6.1V Quad Array
Data Sheet
0-1: $0.30
1-10: $0.25
10-100: $0.19
100-250: $0.17
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
ESDA12-1K
ESDA12-1K
STMicroelectronics
ESD Suppressors EOS ESD Transil 450W 12V, 18V 150pF
Data Sheet
0-1: $0.27
1-10: $0.21
10-100: $0.17
100-250: $0.14
ESDA14V2-1BF3
ESDA14V2-1BF3
STMicroelectronics
TVS Diodes - Transient Voltage Suppressors Single Line Bi-Di ESD Transil Array
Data Sheet
0-1: $0.24
1-10: $0.19
10-100: $0.14
100-250: $0.10
ESDA14V2-2BF3
ESDA14V2-2BF3
STMicroelectronics
TVS Diode Arrays Dual bidirectional TRANSIL" array
Data Sheet
0-3250: $0.13
3250-5000: $0.11
5000-10000: $0.11
ESDA14V2-4BF1
ESDA14V2-4BF1
STMicroelectronics
TVS Diode Arrays Quad Bidirect Array
Data Sheet
Negotiable
ESDA14V2-4BF2
ESDA14V2-4BF2
STMicroelectronics
TVS Diode Arrays Quad Bidirect Array
Data Sheet
Negotiable
ESDA14V2-4BF3
ESDA14V2-4BF3
STMicroelectronics
TVS Diode Arrays Quad BI ESD prote TRANSIL" array
Data Sheet
0-1: $0.30
1-10: $0.27
10-100: $0.20
100-250: $0.18
