The VJ0402A560JNAAJ is a surface mount multilayer ceramic chip capacitor for TCC critical application.
Parametrics
VJ0402A560JNAAJ absolute maximum ratings: (1)Capacitance Range: 120 pF to 2.7 μF; (2)Voltage Range: 25 Vdc to 100 Vdc; (3)Temperature Coefficient of Capacitance (TCC): + 15 %, - 25 % from - 55 ℃ to + 125 ℃, with rated voltage applied ± 15 % from - 55 ℃ to + 125 ℃, with 0 Vdc applied; (4)Dissipation Factor (DF): 2.5 % maximum at 1.0 Vrms and 1 kHz; (5)Aging Rate: 1 % maximum per decade.
Features
VJ0402A560JNAAJ features: (1)Designed for excellent T/VCC; (2)Temperature voltage coefficient (T/VCC) does not exceed - 25 % at rated voltage; (3)Excellent aging characteristics; (4)Surface mount, precious metal technology, wet build process.
Diagrams
