Product Summary
The MAX1921EUT15+T step-down converter delivers over 400mA to outputs as low as 1.25V. The MAX1921EUT15+T uses a unique proprietary current-limited control scheme that achieves over 90% efficiency. The MAX1921EUT15+T maintains extremely low quiescent supply current (50μA), and its high 1.2MHz (max) operating frequency permits small, low-cost external components. This combination makes the MAX1921EUT15+T an excellent high-efficiency alternative to linear regulators in space-constrained applications.
Parametrics
MAX1921EUT15+T absolute maximum ratings: (1)IN, FB, SHDN to AGND: -0.3V to +6V; (2)OUT to AGND, LX to PGND: -0.3V to (IN + 0.3V); (3)AGND to PGND: -0.3V to +0.3V; (4)OUT Short Circuit to GND: 10s; (5)Operating Temperature Range: -40°C to +85°C; (6)Junction Temperature: +150°C; (7)Storage Temperature: -65°C to +150°C; (8)Lead Temperature (soldering 10s): +300°C; (9)Continuous Power Dissipation (TA = +70°C)6-Pin SOT23: 696mW.
Features
MAX1921EUT15+T features: (1)Low-Voltage, 400mA Step-Down DC-DC Converters in SOT23; (2)Package Type: 6-Lead SOT23; (3)Dimensions: 60 x 41 mils.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 MAX1921EUT15+T |
Maxim Integrated Products |
DC/DC Switching Converters 400mA Step-Down DC/DC Converter |
Data Sheet |
|
|
||||||||||||
