LMV711M6X

single low-power rrio operational amplifier, SOT, 6V, ±10 mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.00~0.05 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
100 ~ 10000 :	0.05 / Piece
10000 ~ 50000 :	0.00 / Piece

PartNumber:: LMV711M6X

Brand:: National Semiconductor - NS | Pack: SOT | D/C: 10+

Availability:: Supply Ability: 50000/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Jolin's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-04

From Other Seller

Part Number:LMV711M6X
US $0.00 - 0.05
Quantity:

piece

Product Summary

The LMV711M6X is a single BiCMOS operational amplifiers designed to meet the demands of low power, low cost, and small size required by battery-powered portable electronics. The LMV711M6X has an input common-mode voltage range that exceeds the rails, rail-to-rail output, and high output-current drive. The devices offer a bandwidth of 5 MHz and a slew rate of 5 V/ µ s. The applications of the LMV711M6X are Wireless Phones, Mobile Phones, PDAs, GSM/TDMA/CDMA Power Amp Control, AGC, RF Power Detectors, Temperature Compensation, Wireless LANs, Bluetooth, HomeRF.

Parametrics

LMV711M6X absolute maximum ratings: (1)Supply voltage:6V; (2)Differential input voltage:±6V; (3)Input voltage (either input): V CC- - 0.4 to V CC+ + 0.4 V; (4)Output voltage: V CC- - 0.4 to V CC+ + 0.4 V; (5)Input current:±10 mA.

Features

LMV711M6X features: (1)2.7-V and 5-V Performance; (2)Low Offset Voltage: 0.4 mV Typ, 3 mV Max; (3)Input Common-Mode Range: 200 mV; (4)Beyond the Rails; (5)Rail-to-Rail Swing Into 600 Ω; (6)Gain Bandwidth: 5 MHz Typ; (7)Slew Rate: 5 V/ μ s Typ; (8)Turn-On Time From Shutdown: <10 μ s; (9)Shutdown Current: 0.2 μ A Typ.
