MAX4073FAUT

MAX4073FAUT, 3 to 28V, SC70, ±20mA, High-Side Current-Sense Amplifier, 200mW

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.01~0.05 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
100 ~ 10000 :	0.05 / Piece
10000 ~ 50000 :	0.01 / Piece

PartNumber:: MAX4073FAUT

Brand:: Maxim Integrated Products - Maxim | Pack: SOT | D/C: 10+

Availability:: Supply Ability: 50000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Jolin's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-18

From Other Seller

Part Number:MAX4073FAUT
US $0.01 - 0.05
Quantity:

piece

Product Summary

The MAX4073FAUT is a Low-Cost, SC70, Voltage-Output, High-Side Current-Sense Amplifier. The applications of the MAX4073FAUT are Cell Phones, Notebook Computers, Portable/Battery-Powered Systems, Smart Battery Packs/Chargers, PDAs, Power Management Systems, PA Bias Control, General System/Board-Level Current Monitoring, Precision Current Sources.

Parametrics

MAX4073FAUT absolute maximum ratings: (1)VCC to GND: -0.3V to +30V; (2)RS+, RS- to GND: -0.3V to +30V; (3)OUT to GND: -0.3V to (VCC + 0.3V); (4)Output Short-Circuit to GND: Continuous; (5)Differential Input Voltage (VRS+ - VRS-): ±5V; (6)Current Into Any Pin: ±20mA; (7)Continuous Power Dissipation (TA = +70°C): 200mW; (8)Operating Temperature Range: -40°C to +125°C; (9)Junction Temperature: +150°C; (10)Storage Temperature Range: -65°C to +150°C; (11)Lead Temperature (soldering, 10s): 300°C.

Features

MAX4073FAUT features: (1)Low-Cost, Compact, Current-Sense Solution; (2)±1.0% Full-Scale Accuracy; (3)500μA Supply Current; (4)Wide 1.8MHz Bandwidth; (5)+3V to +28V Operating Supply; (6)Wide +2V to +28V Common-Mode Range Independent of Supply Voltage; (7)Automotive Temperature Range (-40°C to +125°C); (8)Available in Space-Saving 5-Pin SC70 Package.
