PIC16F917-I/PT

8-bit CMOS microcontroller, DIP, -0.3V to +6.5V, Multiplexed Master Clear

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.01~100.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.01~100.00

PartNumber:: PIC16F917-I/PT

Brand:: Microchip Technology - Microchip | Pack: TQFP | D/C: 07+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Jolin's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-15

From Other Seller

Part Number:PIC16F917-I/PT
US $0.01 - 100.00
MSP430F5438IPZ

US $10.00 - 15.00 / Piece
(0) Remove
W25X32VSIG

US $0.80 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The PIC16F917-I/PT is a 28/40/44-Pin flash-based, 8-bit CMOS microcontroller with LCD driver and nanoWatt technology. It is available in 28/40/44-pin packages.

Parametrics

PIC16F917-I/PT absolute maximum ratings: (1)Ambient temperature under bias: -40℃ to +125℃; (2)Storage temperature: -65℃ to +150℃; (3)Voltage on VDD with respect to VSS: -0.3V to +6.5V; (4)Voltage on MCLR with respect to Vss: -0.3V to +13.5V; (5)Voltage on all other pins with respect to VSS: -0.3V to (VDD + 0.3V); (6)Total power dissipation: 800mW; (7)Maximum current out of VSS pin: 300mA; (8)Maximum current into VDD pin: 250mA; (9)Input clamp current, IIK (VI < 0 or VI > VDD): ±20mA; (10)Output clamp current, IOK (Vo < 0 or Vo >VDD): ±20mA.

Features

PIC16F917-I/PT features: (1)Power-saving Sleep mode; (2)Wide operating voltage range (2.0V-5.5V); (3)Industrial and Extended temperature range; (4)Power-on Reset (POR); (5)Power-up Timer (PWRT) and Oscillator Start-up Timer (OST); (6)Brown-out Reset (BOR) with software control option; (7)Enhanced Low-Current Watchdog Timer (WDT) with on-chip oscillator (software selectable nominal 268 seconds with full prescaler) with software enable; (8)Multiplexed Master Clear with pull-up/input pin; (9)Programmable code protection.
