MAX485

MAX485, Slew-Rate-Limited, RS-485/RS-422 Transceiver, 8SOIC, +3.3V, 800mW

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~50.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~50.00

PartNumber:: MAX485

Brand:: Maxim Integrated Products - Maxim | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Jolin's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-06-06

From Other Seller

Part Number:MAX485
US $1.00 - 50.00
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MAX485 is a low-power transceiver. It is designed as one kind of ±15kV ESD-protected, slew-rate-limited, low-power, RS-485/RS-422 transceiver device. The MAX485 can be used in wide range of applications such as (1)low-power RS-485 transceivers; (2)low-power RS-422 transceivers; (3)Level translators; (4)transceivers for EMI-sensitive applications; (5)industrial-control local area networks. Also this device features reduced slewrate drivers that minimize EMI and reduce reflections caused by improperly terminated cables.

Parametrics

MAX485 absolute maximum ratings: (1)Supply Voltage (VCC): 12V; (2)Control Input Voltage (RE, DE): -0.5V to (VCC + 0.5V); (3)Driver Input Voltage (DI): -0.5V to (VCC + 0.5V); (4)Driver Output Voltage (A, B): -8V to +12.5V; (5)Receiver Input Voltage (A, B): -8V to +12.5V; (6)Receiver Output Voltage (RO): -0.5V to (VCC +0.5V); (7)Continuous Power Dissipation (TA = +70℃); (8)8-Pin Plastic DIP (derate 9.09mW/℃ above +70℃): 727mW; (9)14-Pin Plastic DIP (derate 10.00mW/℃ above +70℃): 800mW; (10)8-Pin SO (derate 5.88mW/℃ above +70℃): 471mW.

Features

MAX485 features: (1)For Fault-Tolerant Applications; (2)For Space-Constrained Applications; (3)For Multiple Transceiver Applications; (4)For Fail-Safe Applications; (5)For Low-Voltage Applications.
